  • U7-PRO-XGS-B
  • U7-PRO-XGS-B
  • U7-PRO-XGS-B
  • U7-PRO-XGS-B
  • U7-PRO-XGS-B

    • U7-PRO-XGS-B

    USD299.00
    (No reviews yet) Write a Review
    SKU:
    U7-PRO-XGS-B
    Condition:
    New
    Weight:
    1.60 KGS
    Adding to cart… category.add_cart_announcement

    Product Description


    Dimensions
    ⌀215 x 32.5 mm (⌀8.5 x 1.3")
    WiFi Standard
    WiFi 7
    Spatial Streams
    8
    Coverage Area
    160 m² (1,750 ft²)
    Max. Client Count
    500+
    Uplink
    10 GbE
    Mounting
    Ceiling, Wall (Lite Mount Included)
    Power Method
    PoE++


    MIMO


    6 GHz
    2 x 2 (DL/UL MU-MIMO)


    5 GHz
    4 x 4 (DL/UL MU-MIMO)


    2.4 GHz
    2 x 2 (DL/UL MU-MIMO)
    Max. Data Rate


    6 GHz
    5.8 Gbps (BW320)


    5 GHz
    8.6 Gbps (BW240)


    2.4 GHz
    688 Mbps (BW40)
    Antenna Gain


    6 GHz
    6 dBi


    5 GHz
    6 dBi


    2.4 GHz
    4 dBi
    Max. TX Power


    6 GHz
    24 dBm


    5 GHz
    29 dBm


    2.4 GHz
    23 dBm
    Max. BSSIDs
    8 per Radio
    Supported Data Rates


    802.11be (WiFi 7)
    6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320) 5 GHz: 7.3 Mbps to 8.6 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240)


    802.11ax (WiFi 6)
    7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)


    802.11ac (WiFi 5)
    6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)


    802.11n
    6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)


    Wireless Meshing
    ✓
    Band Steering
    ✓
    802.11v BSS Transition Management
    ✓
    802.11r Fast Roaming
    ✓
    802.11k Radio Resource Management (RRM)
    ✓
    Zero-Wait DFS
    ✓
    Advanced Radio Management
    ✓
    Real-Time Spectral Analysis
    ✓
    Passpoint (Hotspot 2.0)
    ✓
    Captive Hotspot Portal


    Custom Branding Landing Page
    ✓


    Voucher Authentication
    ✓


    Payment-Based Authentication
    ✓


    External Portal Server Support
    ✓


    Password Authentication
    ✓


    Guest Network Isolation
    ✓
    Private Pre-Shared Key (PPSK)
    ✓
    WiFi Speed Limiting
    ✓
    Client Device Isolation
    ✓
    WiFi Schedules
    ✓
    RADIUS over TLS (RadSec)
    ✓
    Dynamic RADIUS-assigned VLAN
    ✓


    Max. Power Consumption
    29W
    Supported Voltage Range
    42.5–57V DC
    Networking Interface
    (1) 10 GbE RJ45 port
    Weight
    800 g (1.8 lb)
    Management
    Ethernet
    Enclosure Material
    UV-stabilized polycarbonate, aluminum alloy
    Mount Material
    Stainless steel (SUS304), galvanized steel (SGCC)
    LEDs


    System
    White/Blue
    Channel Bandwidth
    HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)
    NDAA Compliant
    ✓
    Certifications
    CE, FCC, IC, Anatel: 05123-25-08356
    Operating Frequency
    US/CA: 2400 - 2472 MHz U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz U-NII-5 to U-NII-8: 5925 - 7125 MHz Worldwide: 2400 - 2483.5 MHz 5150 - 5850 MHz 5925 - 7125 MHz
    Ambient Operating Temperature
    -30 to 40° C (-22 to 104° F)
    Ambient Operating Humidity
    5 to 95% noncondensing
