TBS2631SE 8 channel HD Live Stream IPTV Encoder

USD1,800.00
(No reviews yet) Write a Review
Weight:
8.00 KGS
Bulk Pricing:
Buy in bulk and save

TBS2631SE 8-Channel HDMI Encoder can realize 8-channel HDMI collection, real-time HD encoding and RTMP forwarding. Compared with current mainstream coding machine solution, its coding efficiency increased by 50%, power consumption drop 65%, 80% reduction in volume. It is an innovative network HD broadcast coding machine.

TBS2631SE highly integrated hardware and software. It is convenience for customers release RTMP streams into streaming media server.

TBS2631SE will greatly save the network traffic, electricity and space utilization rate, improve the live operator front-end equipment reliability, reduce operating costs and entry barriers



Features:

  • 8 channel HDMI capture, real-time HD encoding
  • RTMP streams into IPTV streaming media server
  • Support 1080i@50 resolution
  • Support multiple equipments display at the same time on a computer
  • 1U chassis , low power consumption, less than 70W
  • Greatly save on network traffic, electricity and space usage
  • Add/Remove water-mark dynamically
  • Sample software UI



Application:

  • IPTV
  • Video Conference
  • Live Broadcast
  • Teaching/Campus Broadcast



How it work?



Specification:

Input Interface 8 x HDMI
Output RJ45 100/1000Mbps
HD format 720p@50/60, 1080i@50
Protocol RTMP/UDP/RTP/HTTP
AC in 110/220
AC rate 50/60Hz
Power consumption Less than 70W
Encoding quality
Excellent 1.3Mbps
Good 1.0Mbps
Fair 800Kbps
Poor 600Kbps
OS Linux
Size 1U chassis
Weight 4kg
