Introducing airFiber®, a truly revolutionary Point-to-Point wireless platform from Ubiquiti Networks. Housed in a compact, highly efficient form factor, airFiber delivers amazing wireless gigabit+ performance, low latency, and long range. airFiber ushers in a new era in price-disruptive wireless technology ideal for carrier backhaul, building-to-building enterprise use, or public safety applications.
Ubiquiti’s innovative proprietary modem technology was purpose-built to address the specific challenges of outdoor, PtP (Point‑to-Point) bridging and high-performance network backhauls. Every aspect of the radio has been carefully simulated and designed to optimize range, speed, and latency performance in the harshest RF noise environments.
airFiber AF-24/AF-24HD provides a breakthrough in 24 GHz backhaul performance.
The standard model, AF-24, delivers up to 1.4+ Gbps throughput at a range of up to 13+ km.
The heavy-duty model, AF-24HD, provides more throughput at up to 2 Gbps and increased range of up to 20+ km. It also includes a more rugged exterior with a metal reflector, to protect against nature’s harshest elements.
Two units are required for a complete link.
- High-band 5 GHz frequencies 24.05 - 24.25 GHz
- (1) 10/100/1000 Ethernet Port
- (1) 10/100 Ethernet Port
- (1) RJ-12, Alignment Tone Port
- 50V, 1.2A PoE GigE Adapter (Included)
- Passive PoE
- Pole Mount Kit (Included)
